Carefulness is the premise, fineness is the key,percision is the core,and excellence is our goal and pursuit. Careful design,careful processing ,standardized production ,efficient operation.
6 Years
| Ask Lasest Price | |
| Brand Name : | TXH |
| Model Number : | 219-1620 |
| Certification : | ISO CE |
| Price : | USD 200000-400000 |
| Payment Terms : | L/C, T/T |
| Supply Ability : | 10 sets/ year |
| Delivery Time : | 2-3 months |
1.Machine Description
Spiral steel pipe machine is used to manufacture spiral seam welded pipe.
It can produce steel pipes of different diameters with strips of the same width, and produce steel pipes of the same diameter with strips of different widths. Spiral pipe welding machine (spiral steel pipe machine) is mainly for front swing type and rear swing type.This machine is composed of uncoiler, feeding, straightening, shearing, receiving, trimming, delivering, input guide plate, forming, steel pipe internal and external welding, pipe cutting output and pipe turnover
2.Machine quick detailes
Coil Specification
Marital: Q235, Q345
Coil thickness: 5 - 16mm
Coil width: 700-1500 mm
Max. coil weight: 25T
Product specification
Pipe O.D. : Φ219-Φ1620mm
Pipe thickness: 5-16mm
Pipe length: 8 - 12m
1- Uncoiler
1- Peeler
2- Hydraulic vertical roller
1- Shear and butt welding device
1- 5 roll leveling machine
1- Edge Planer Machine
1- Delivery machine
1- Front bridge
1- Guide plate
1- Forming machine
1- Inner welding device
1- Outer welding device
1- Plasma cutting device
1- Rear bridge
1- Center support
1- Hydraulic system
1- Electrical control system
4. Model
| Model | Pipe diameter(mm) | Pipe thickness(mm) | Coil width (mm) |
| SAW 508 | Φ219-Φ508 | 4-10 | 400-800 |
| SAW 610 | Φ219-Φ610 | 4-10 | 400-1000 |
| SAW 820 | Φ219-Φ820 | 4-12 | 400-1250 |
| SAW1020 | Φ219-Φ1020 | 4-14 | 500-1250 |
| SAW 1220 | Φ219-Φ1220 | 4-14 | 500-1500 |
| SAW 1420 | Φ400-Φ1420 | 4-16 | 500-1500 |
| SAW 1620 | Φ400-Φ1620 | 4-16 | 500-1500 |
| SAW 1820 | Φ508-Φ1820 | 4-20 | 1000-1800 |
| SAW 2220 | Φ508-Φ2220 | 4-22 | 1000-1800 |
| SAW2540 | Φ508-Φ2540 | 4-25.4 | 1000-2000 |
5.Usage
6.Customer service
Before signing an official contract with our customer we will help
to analyze and provide professional solution based on customer
project information and come out with optimum solution.
Your inquiry related to our products or price will be replied in
24hrs.
Keep informing our customer production process and help arrange
quality checking in the factory if necessary.
One-year warranty to our display and one-year warranty to spare
parts.
Buyer can dispatch technician to our factory for free training
before delivery.
For essential equipment failure, we will arrange our engineer head
to local site toinstall, also provide online technical support for
the whole life.
|
|
